相信很多非人事不太容易區分仿威圖機柜和普通機柜之間的差別，哪么今天小編為大家分析一下兩者之邊的區別。

It is believed that many non professional personnel are not easy to distinguish between imitation Rittal cabinets and ordinary cabinets. So today, I will analyze the differences between the two.

通俗講就是仿照德國威圖柜的產品，威圖柜子對于表面處理要求很高防護等級也要求比別的高，但現在國內用的多是仿威圖柜其主要原因是原裝的威圖柜太貴，仿威圖柜相比便宜許多但其功能上來說都是一樣的，仿威圖柜其實就目前而言國內一般好一點一點的廠家都能生產。所以現在國內市場仿威圖柜的市場占有早以超越真正的德國威圖柜。

Generally speaking, it is a product that imitates German Rittal cabinets. Rittal cabinets require a high level of surface treatment and protection compared to other products. However, nowadays, most of the products used in China are imitation Rittal cabinets. The main reason is that the original Rittal cabinets are too expensive, and the imitation Rittal cabinets are much cheaper, but their functions are the same. In fact, at present, imitation Rittal cabinets are generally produced by better and more professional manufacturers in China. Therefore, the market share of imitation Rittal cabinets in the domestic market has already surpassed that of genuine German Rittal cabinets.

所以說國內大多數企業只要要求不是很嚴格，一般的話仿威圖柜完完全全就能達到企業的需求。

Therefore, as long as the requirements of most domestic enterprises are not very strict, generally speaking, the imitation of Rittal cabinets can completely meet the needs of the enterprise.

1.威圖柜從構造上可分為3大系列，ES柜（五折型材柜），PS柜（九折型材柜），TS柜（十六折型材柜），大的特色即是威圖柜是選用型材構造構造，先將柜子的構造焊接好，然后頂板、底板、側板、門板、裝置板用螺絲固定在構造上這樣的優點即是商品模塊化構造運用便利；

1. Rittal cabinets can be divided into three major series in terms of structure: ES cabinet (50 fold profile cabinet), PS cabinet (9 fold profile cabinet), and TS cabinet (16 fold profile cabinet). The major feature is that Rittal cabinets are constructed using profile materials. Firstly, the structure of the cabinet is welded, and then the top plate, bottom plate, side plate, door panel, and device panel are fixed with screws. This advantage is that the modular structure of the commodity is convenient to use;

2.商品美觀l機柜從工業品的運用和外觀上都尋求完滿的理念，從鈑金構造規劃和附件的調配運用也非常合理科學形成了標準化的配套規劃；

2. The product is beautiful. The cabinet seeks a complete concept from the use and appearance of industrial products, and a standardized and scientific supporting plan has been formed from the planning of sheet metal structure and the allocation and application of accessories;

3.運用便利，內部的縱梁、立柱、橫梁、走線條及自身的模塑化孔的規劃使得用戶裝置都顯得得心應手、便利自若；

3. Convenient use. The planning of internal longitudinal beams, columns, beams, routing lines, and their own molded holes makes the user's device seem handy and convenient;

4.健壯耐用、可靠威圖柜構造構造使得構造穩固，單柜大可承重2000KG不懼裝置任何粗笨器材；

4. Robust, durable, safe, and reliable Rittal cabinet construction ensures a stable structure, and a single cabinet can bear a load of 2000 KG without fear of installing any bulky equipment;

5.一起仿威圖機柜從資料上別離碳鋼和不銹鋼料厚默許為門板2.0mm，裝置板2.5mm，柜體1.5mm；

5. A simulated Rittal cabinet is separated from carbon steel and stainless steel in terms of data. The default thickness is 2.0mm for the door plate, 2.5mm for the device plate, and 1.5mm for the cabinet body;

6.碳鋼的外表處理默許為噴塑處理噴塑前做磷化底涂處理，不銹鋼的外表處理默許技術為拉絲處理。

6. The surface treatment of carbon steel implicitly refers to the phosphating primer treatment before plastic spraying, while the surface treatment of stainless steel implicitly refers to the wire drawing treatment.

仿威圖機柜和普通機柜之間的區分方法就講解到這里了，您對此有怎樣的疑惑或者需求，就來我們網站http://www.zhaowenjy.com咨詢了解吧！

This is the way to distinguish between imitation Rittal cabinets and ordinary cabinets. If you have any doubts or needs about this, please come to our website http://www.zhaowenjy.com  Consult and understand!
